TM 5-2330-325-13&P
FIELD MAINTENANCE
FRONT AND MIDDLE AXLE MAINTENANCE
INITIAL SETUP:
Tools and Special Tools
References
Tool Kit, General Mechanic's
(WP 0144, Table 1, Item 16)
Jack, Dolly Type (WP 0144, Table 1, Item 10)
Equipment Condition
Jack Stand (WP 0144, Table 1, Item 11)
Wheel and tire assemblies removed (WP 0038)
Brake shoes removed (WP 0057)
Materials/Parts
Slack adjusters removed (WP 0059)
Bolt Qty: (16) (WP 0104, Figure 7, Item 4)
Air brake chambers removed (WP 0069)
Nut, Self-Locking
Brake camshafts removed (WP 0058)
Qty: (16) (WP 0104, Figure 7, Item 1)
ABS sensor removed (WP 0062)
Personnel Required
Two
WARNING
Suitable lifting device and suitable support need to be rated at no less than
20,000 lb (9,071 kg). Failure to comply may result in death or injury to personnel.
Seek medical attention in the event of an injury.
Semitrailer must be supported at front and rear to prevent shifting. All weight must
be taken off the suspension components. Failure to comply may result in death or
injury to personnel. Seek medical attention in the event of an injury.
