TB 9-2320-279-13&P-2
DOOR ASSEMBLY REPLACEMENT - CONTINUED
0015 00
REMOVAL - CONTINUED
5.
Remove 10 locknuts (14), washers (15), and bolts (16) from door assembly (1). Discard locknuts.
6.
Use lifting device to remove door assembly (1) from door frame and place on flat surface.
7.
Remove sling and lifting device from door assembly (1).
8.
Remove two locknuts (12), washers (11), bolts (10), and lifting links (13). Discard locknuts.
1
13
10,11,12
14,15,16
17
417-047
CLEANING AND INSPECTION
Clean and inspect all parts IAW General Maintenance Instructions (WP 0011 00).
0015 00-3
